Flasks Round Bottom,Centre Neck and Three Parallel Side Neck, with Interchangeable Joints
Uniform wall thickness distribution makes these Flasks ideal for heating and withstand the pressure require-ments especially when gaseous reagents are involved.
Proper dimensions to ensure proper capacity is adhered to.
Interchangeable joint.
Accessories, thermometer, column, dropping funnels can be fitted as per requirement.
All four necks are vertical , 2 side necks are 180 degree apart and other one is 90 degree to them.
PURPOSE: Generally used for distillation ,extraction process and other processes involving more complex reactions with multiple reagents involved.
Cat. No | Nominal capac-ity ml | Centre Socket | Side Sock-et Size | Approx overall height mm. | Price / Unit |
---|---|---|---|---|---|
055.MD.01 | 100 | 14/23 | 14/23 | 250 | |
055.MD.02 | 100 | 19/26 | 14/23 | 115 | 250 |
055.MD.03 | 100 | 24/29 | 14/23 | 115 | 250 |
055.MD.04 | 100 | 24/29 | 19/26 | 115 | 250 |
055.MD.05 | 100 | 29/32 | 14/23 | 115 | 300 |
055.MD.06 | 250 | 19/26 | 14/23 | 145 | 340 |
055.MD.07 | 250 | 24/29 | 14/23 | 145 | 340 |
055.MD.08 | 250 | 24/29 | 19/26 | 145 | 340 |
055.MD.09 | 250 | 29/32 | 14/23 | 145 | 340 |
055.MD.10 | 250 | 29/32 | 19/26 | 145 | 340 |
055.MD.11 | 250 | 29/32 | 19/26 | 145 | 500 |
055.MD.12 | 500 | 24/29 | 14/23 | 175 | 500 |
055.MD.13 | 500 | 24/29 | 19/26 | 175 | 500 |
055.MD.14 | 500 | 29/32 | 19/26 | 175 | 500 |
055.MD.15 | 1000 | 24/29 | 14/23 | 210 | 640 |
055.MD.16 | 1000 | 24/29 | 19/26 | 210 | 640 |
055.MD.17 | 1000 | 24/29 | 24/28 | 210 | 640 |
055.MD.18 | 1000 | 24/29 | 14/23 | 210 | 640 |
055.MD.19 | 2000 | 29/32 | 19/26 | 260 | 1500 |
055.MD.20 | 2000 | 24/29 | 14/23 | 260 | 1500 |
055.MD.21 | 2000 | 34/35 | 24/29 | 290 | 1500 |
